TP500 Tractive Unit

Up to 8000kg on castors or 40000kg on rails



Our TP500HD Tractive pusher is pedestrian-operated and battery powered, designed to push and pull train wheelsets and bogeys. Used in rail applications this Tractive unit will move up to 50,000kg. They ensure that operators can enjoy safe and efficient handling at all times. Simple to use, robust, and ergonomically designed, we believe these electric tug units are the best on the market!

The additional weight of this machine is specifically designed to ensure traction is maintained at all times to ensure moving the wheelsets is controlled.

Explore our range of Tractive Tugs which help to move loads on castors

Description

Our TP500 Tractive pusher is pedestrian-operated and battery-powered, designed to push and pull loads up to 50000kg on rails and 12000kg on castors. They ensure that operators can enjoy safe and efficient handling at all times. Simple to use, robust, and ergonomically designed, we believe these electric tug units are the best on the market!

The additional weight of this machine is specifically designed to ensure traction is maintained at all times to ensure moving the loads is controlled.

Explore our range of Tractive Tugs which help to move loads on castors



Draw Bar Pull (N) 5000
Towing Capacity on Rails (Kg) 40000
Towing Capacity on Castors (Kg) 8000
Drive System AC
Motor Power (W) 1500
Battery Capacity (Ah) 80
Max Speed (Kph) 6
Turning Circle (M) 1.5
Machine Weight (Kg) 440
Drive Wheel Type Solid Rubber Treaded
Hare/Tortoise Switch Option
Strobe Light Option
Audible Alarm Option
Keypad Stattup Option
Interchangeable battery pack Option
Lithium Ion Option
Wireless Radio FWD/REV Option
Stainless Steel Option
